Designed for small batch filling.
Reduce human intervention to guarantee the asepsis and containment.
Customized and modular designed.
Class A, ISO5, Aseptic environment.
Integrated VHPS? decontamination system.
Real time monitoring the velocity, differential pressure, humidity, temperature.
Temperature is adjustable to minimize the influence to products.
Critical process parameters can be stored and printed.
Power Supply: AC 380V/50Hz
Siemens PLC control with HMI
Leakage rate is less than 0.5% /vol/hour at 2 times working pressure
LED lamp, more than 300 Lux.
Rapid Transfer Ports (RTP) technology for safe transfer.
Particle counter
Air sampler
H2O2 high & low concentration sensors
H2O2 portable sensor for operator safety
WiFi controlled glove integrity tester (GIT-WLAN)
Wooden Mock-Up
Complete validation protocols to comply with FDA, EMA, GMP, 21CFR Part 11.
FAT, SAT, Training.
Technical specifications are subject to change without notice. Copyright reserved by Tailin.
